Product Description
1. Android RK3288, RK3399 or RK3128, support Linux. Optional Windows J1900, I3, I5;
2. Optional storage and memory;
3. Support OEM/ ODM.
4. IP65 for front touch panel;
Specification
Please noted, the below specifications for DWE801MOD10, if have any questions or needs contact us feel free.
We also supply 7inch, 8inch, 10.1inch, 15.6inch, 21.5inch, etc industrial touch panels. Optional Windows, Android system.
Support desktop bracket, wall-mounted bracket and top bracket.
If you need barcode scanners please click here!
|
CPU
|
RK3288
4-core Cortex-A17 architecture, the highest frequency is 2GHz |
|
GPU
|
ARM MALI-T764）
|
|
Memory /storage
|
Standard 2G (4G optional) / EMMC standard 16G (8G/32G/64G optional)
|
|
audio and video output
|
Support left and right channel output, built-in dual 8R/5W power amplifier
|
|
Earphone
|
Support one headphone jack
|
|
USB
|
1* USB2.0(Support OTG/HOST switching); 7* USB2.0 HOST;
8*USB in total |
|
Serial port
|
4*RS232, 2*485，1* TTL，1* DEBUG total 8 serial port
|
|
Mipi Camera
|
Dual channel supports dual camera 30pin FPC interface, supports 1300w Camera
|
|
TF card
|
Support TF card
|
|
WIFI、BT
|
Built-in WIFI, BT4.0 (optional) WIFI module, support WIFI hotspot sharing during 4G communication
|
|
3G/4G
|
Built-in WCDMA, EVDO, 4G full Netcom expansion interface
|
|
Screen size
|
10.1 inch
|
|
LCD screen
|
capacitive touch
|
|
contrast
|
900:1 (Typ.) (Transmission)
|
|
Resolution
|
1280(RGB)×800
|
|
Screen ratio
|
16 : 10
|
|
Operating temperature
|
-20℃ ~ 70℃,≤80% RH
|
|
Storage humidity
|
-30℃ ~ 70℃,≤80% RH
|
|
Response time
|
≤16ms
|
|
Normal power
|
≤30W
|
|
Screen pitch
|
0.0565×0.1695 mm (H×V)
|
